WEST SANTA FE

QUICK FACTS

OWNERSHIP

100% Lahontan Gold via 7 year option agreement

LOCATION

Mineral County, Walker Lane – Nevada

LAND PACKAGE

11.8 Km2

PROJECT HISTORY

Previous drilling totals over 13,000 metres in 171 drill holes; only five holes are deeper than 165 metres. 2025: 7 RC drill holes twinning historic holes to confirm historic data accuracy.

2026 WORK PLAN

3,500 meters of additional reverse circulation (RC) drilling at West Santa Fe to further expand and define mineralization.

KEY TAKEAWAY

Bolt On Project With Excellent Resource Potential.

  • ABOUT
  • GEOLOGY
  • EXPLORATION DATABASE
  • 2025 Drilling

The advanced West Santa Fe gold-silver project is located only 15 km West of the Flagship Santa Fe Mine and hosts an oxidized gold-silver mineralized system in a geologic setting nearly identical to Santa Fe.

Modeling of historical drill hole data by Lahontan geologists outlines a shallow gold and silver system with a sufficient volume to host 0.5 to 1.0M ounces of oxidized gold and silver mineralization in an open-pit mining configuration*

*The exploration target at West Santa Fe is conceptual in nature and is based on the size of the known mineralized zones, and gold and silver grades from historical drilling. The qualified person has not completed sufficient work to verify the historical information on West Santa Fe and this information should not be relied on.

Gold and silver mineralization at West Santa Fe occurs as a sediment-hosted epithermal Au-Ag system hosted by Triassic age carbonate and volcanic rocks, a setting very similar to the Santa Fe Mine. Shallow gold and silver mineralization are localized to East-Northeast trending faults and offset by Northwest striking faults, a classic Walker Lane setting.  In addition to over 13,000 metres of drilling, previous exploration activity at West Santa Fe includes: Geophysical studies including IP and aerial magnetic surveys, geochemical surveys including over 1,250 soil samples, and detailed geologic mapping.

Modeling of the historical drill hole data by Lahontan geologists defines a continuous zone of gold and silver mineralization which extends from the surface down-rake to the East-Northeast.  Utilizing a 0.31 g/t gold mineralized shell defined by historical drill hole data, outlines a large continuously mineralized area at West Santa Fe that has the potential to host a significant gold and silver resource1 (please see diagram below).  Additional exploration drilling will be needed to define mineral resources and to validate the historical drill hole data base.

[1] The exploration target at West Santa Fe is conceptual in nature and is based on the size of the known mineralized zones, and gold and silver grades from historical drilling. The qualified person has not completed sufficient work to verify the historical information on West Santa Fe and this information should not be relied on.

Simple representation of drill holes and gold-silver mineral potential at West Santa Fe. Cross section looks West-Southwest with South-Southwest to the left and North-Northeast to the right. Grade shell is 0.31 g/t Au and is continuous in the mineralized zones. Within the core of the mineralized area, grades exceed 1.5 g/t gold. Mineralization extends down-dip to the Northeast for several hundred metres where it remains open at depth and relatively shallow due to topography (please note scale).

Previous exploration drilling at West Santa Fe totals over 13,000 metres in 171 drill holes; only five holes are deeper than 165 metres.

Additional work includes: Geophysical studies including IP and aerial magnetic surveys, geochemical surveys including over 1,250 soil samples, and detailed geologic mapping. Au and Ag occurs as a sediment-hosted epithermal system hosted by Triassic age carbonate and volcanic rocks localized to East-Northeast trending faults

Past exploration, e.g. Ag-in-soil, defines multiple targets outside of areas previously drilled.
West Santa Fe Drill Program Summary

Lahontan completed its maiden reverse circulation (RC) drill program at West Santa Fe, totaling six holes (593 metres) designed to test shallow oxide gold and silver mineralization along the York target area; results confirm thick zones of near-surface mineralization with higher-grade intervals associated with structural controls, and the system remains open for expansion.

West Santa Fe Drill Results – Key Highlights

WSF25-06R

  • 54.9 m (24.4–79.3 m) grading 1.00 g/t Au Eq

  • Including 16.8 m (27.4–44.2 m) grading 1.75 g/t Au Eq

  • Confirms shallow oxide gold-silver mineralization consistent with historic drilling

  • Silver values within the intercept reached up to approximately 176 g/t Ag

WSF25-03R

  • 41.2 m (15.2–56.4 m) grading 1.94 g/t Au Eq

  • Including 9.1 m (42.7–51.8 m) grading 4.14 g/t Au Eq

  • Higher-grade mineralization associated with fault-controlled structures

  • Individual sub-intervals reported up to approximately 12.88 g/t Au Eq

WSF25-01R

  • 6.1 m (38.1–44.2 m) grading 1.53 g/t Au Eq

  • Demonstrates mineralized continuity along the southern structural trend

  • Mineralization remains open to the east

Cross section through drill hole WSF25-03R, West Santa Fe project, Nevada. The results from this drill hole compare favorably with historic drilling, both in the grade of gold mineralization and the geometry. The results in part validate the historic drill hole data and together, demonstrate that gold and silver mineralization is open down-dip to the north-northwest.
Cross section through drill hole WSF25-06R, West Santa Fe project, Nevada. The results from this drill hole compare favorably with historic drilling, both in the tenor of mineralization and the geometry. The results in part validate the historic drill hole data and together, demonstrate that gold and silver mineralization is open down-dip to the north-northwest.
Notes: Au Eq equals Au (g/t) + ((Ag g/t/60)*0.70). Silver grade for calculating Au Eq is adjusted to consider estimated metallurgical recovery reported by Kappes Cassiday (1982). True thickness of the intercepts is estimated to be 70-85% of the drilled interval. Numbers may not total precisely due to rounding.
Notes: Au Eq equals Au (g/t) + ((Ag g/t/60)*0.70). Silver grade for calculating Au Eq is adjusted to consider estimated metallurgical recovery reported by Kappes Cassiday (1982). True thickness of the intercepts is estimated to be 80-100% of the drilled interval. Numbers may not total precisely due to rounding.
Drill hole location map for WSF25-01R and -03R West Santa Fe Project, Nevada. The surface projection of known mineralization, based on historic drilling, is shown in red. Proximity to the Santa Fe Mine project is highlighted by the inset map.
